Tilt-and-slide doors PSK

Application:
Used in many markets, in residential construction, in external structures, as balcony or terrace doors.

Characteristics:
Doors made of window profiles with tilt and slide functionality.
Window threshold (frame type).
The sash runs on an aluminium rail mounted on the face of the profile (inside the room).
Maximum construction width in one frame: 4 metres; maximum sash size: 1800 × 2300 mm with a maximum weight of 200 kg.
A fixed section (fixed) is required in the window, over which the movable (sliding) part overlaps.

Equipment:
Standard: inside handle, automatic hardware.
Options: handle with key or double-sided handle with cylinder.

Advantages:
– a cheaper alternative to lift-and-slide HST doors,
– high airtightness (perimeter fittings and compression seals),
– high thermal insulation,
– large glazed surfaces,
– sliding opening does not take up room space,
– easy operation (automatic hardware causes the sash to move out of the frame automatically when the handle is turned to the “open” position),
– possibility of execution: type A and C.

Execution:
– available in most window systems
